Tilt Switch Probe, Model No. 21-39
The Ramsey tilt switch is actuated when material rises to tilt the probe 15 degrees or more from its vertical position. The mercury switch is precisely positioned so that, regardless of direction of tilt, the normally-closed contacts are caused to open. The switches are encapsulated in various sizes to suit the application.
This product meets CSA approvals for use in Normal and Hazardous Areas (rating of Class I, Divisions 1 and 2, Groups A, B, C, and D T2A, Class II, Division 1, Groups E, F, and G, Class II, Division 2, Groups F, and G Class III T160°C. Ta = 85°C max).
If shown as Sold Out, please contact for quote.
The Ramsey tilt switch is actuated when material rises to tilt the probe 15 degrees or more from its vertical position. The mercury switch is precisely positioned so that, regardless of direction of tilt, the normally-closed contacts are caused to open. The switches are encapsulated in various sizes to suit the application.
This product meets CSA approvals for use in Normal and Hazardous Areas (rating of Class I, Divisions 1 and 2, Groups A, B, C, and D T2A, Class II, Division 1, Groups E, F, and G, Class II, Division 2, Groups F, and G Class III T160°C. Ta = 85°C max).
If shown as Sold Out, please contact for quote.
The Ramsey tilt switch is actuated when material rises to tilt the probe 15 degrees or more from its vertical position. The mercury switch is precisely positioned so that, regardless of direction of tilt, the normally-closed contacts are caused to open. The switches are encapsulated in various sizes to suit the application.
This product meets CSA approvals for use in Normal and Hazardous Areas (rating of Class I, Divisions 1 and 2, Groups A, B, C, and D T2A, Class II, Division 1, Groups E, F, and G, Class II, Division 2, Groups F, and G Class III T160°C. Ta = 85°C max).
If shown as Sold Out, please contact for quote.
Ramsey Cast Iron Tilt Switch Probe 21-39
cCSAus Approvals for Normal and Hazardous Areas
Hazardous area probes MUST be used with hazardous area controls to be rated for hazardous areas
1" Cast Iron Probe with 8 Meter or 15 Meter Cable
Contact Rating: 1 Amp at 24VDC, Non-inductive
Rated for use in applications between -25°F to 180°F
Finish: Nickle Chrome
Rugged, abrasion-resistant tilt switch
Certifications: CSA, cCSAus, CE
All probes include mounting hardware
