Mercury-Free Tilt Sensor Probe, Model No. 21-59-NM
A combination of opto-electronics and solid state circuitry inside the probe prevents jitter and provides stability not found in the typical non-mercury options. The precision manufacturing of the tilt probe provides sensing of a 15 degree inclination in a full 360 degrees of direction. the normally-closed contacts are caused to open. The switches are encapsulated in various sizes to suit the application.
This product meets CSA approvals for use in Normal and Hazardous Areas (rating of Class I, Divisions 1 and 2, Groups A, B, C, and D T2A, Class II, Division 1, Groups E, F, and G, Class II, Division 2, Groups F, and G Class III T160°C. Ta = 85°C max).
If shown as Sold Out, please contact for quote.
A combination of opto-electronics and solid state circuitry inside the probe prevents jitter and provides stability not found in the typical non-mercury options. The precision manufacturing of the tilt probe provides sensing of a 15 degree inclination in a full 360 degrees of direction. the normally-closed contacts are caused to open. The switches are encapsulated in various sizes to suit the application.
This product meets CSA approvals for use in Normal and Hazardous Areas (rating of Class I, Divisions 1 and 2, Groups A, B, C, and D T2A, Class II, Division 1, Groups E, F, and G, Class II, Division 2, Groups F, and G Class III T160°C. Ta = 85°C max).
If shown as Sold Out, please contact for quote.
A combination of opto-electronics and solid state circuitry inside the probe prevents jitter and provides stability not found in the typical non-mercury options. The precision manufacturing of the tilt probe provides sensing of a 15 degree inclination in a full 360 degrees of direction. the normally-closed contacts are caused to open. The switches are encapsulated in various sizes to suit the application.
This product meets CSA approvals for use in Normal and Hazardous Areas (rating of Class I, Divisions 1 and 2, Groups A, B, C, and D T2A, Class II, Division 1, Groups E, F, and G, Class II, Division 2, Groups F, and G Class III T160°C. Ta = 85°C max).
If shown as Sold Out, please contact for quote.
Ramsey Cast Iron Tilt Sensor 21-59-NM
ATEX Zone 20/21 and cCSAus Class I, Div 1 & 2, Groups A, B, C & D and Class II, Div 1 & 2, Group E, F & G, CE
Hazardous area probes MUST be used with hazardous area controls to be rated for hazardous areas
1" Cast Iron, NEMA 4X Probe with 8 Meter or 15 Meter Cable
Contact Rating: 1 Amp at 24VDC, Non-inductive
Rated for use in applications between -40°F to 122°F
Finish: Nickle Chrome
Rugged, abrasion-resistant tilt sensor
Certifications: CSA, cCSAus, CE
All probes include mounting hardware
